advantageous features
● supports 40 voltage channels, 8 thermocouple temperature channels, 4 relay outputs, and 4 digital i/o inputs;
● compatible with multiple sensor types for measuring voltage, temperature, current, pressure, etc.;
● modular design enables flexible expansion of measurement channels;
● customizable auxiliary channels: can be set to work with main channels so that when specific conditions are met, the main channel can stop or switch accordingly;
● automatically acquires voltage, temperature, pressure, and current data from each group, sorts it, and calculates differentials in real time for status evaluation;
● software-based safety protection: configurable upper/lower limits for auxiliary voltage, temperature, pressure, current, and cell voltage deviation;
● supports multiple communication methods, including lan and rs485;
specifications
voltage | 40ch | 0-5v/10v/20v | ±0.05%f.s | 1mv |
temperature | 8ch | -50℃-300℃ | ±1℃ | 0.1℃ |
pressure | 40ch | depends on sensor range | ±0.1%f.s | 1mmpa |
current | 40ch | depends on hall sensor range | ±0.1%f.s | 1ma |
note:for specific models and parameters, please refer to the corresponding technical specifications.
